Name: omnidirectional wheels Intelligent Unmanned Forklift agv lift capacity 2T
Brand: TIANYUE
Price: 1 USD

omnidirectional wheels Intelligent Unmanned Forklift agv lift capacity 2T

Brand Name : TIANYUE

Model Number : TY-ZZ-PHC-2000

Certification : 3c.ce

Place of Origin : GUANGZHOU

MOQ : 1

Payment Terms : T/T

Supply Ability : 100

Delivery Time : 65 wrok days

Packaging Details : wooden box

type : counterweight

load : 1-2T

drive : Mecanum wheel or steering wheel

size : customized

Forklift height : 1700MM

Forklift attachments : customized

Contact Now

Item	Technical Parameters
Product Name	Omnidirectional Unattended Forklift
Product Size	L3500 x W1100 x H2433 mm (customizable)
Load Mode	Front pick-up, lifting height 1700 mm
Rated Load	1500 KG - 2000 KG
Control Mode	PLC, microcontroller (customizable)
Guiding Mode	Laser, QR code, magnetic strip (as required)
Travel Direction	Forward, backward, left turn, right turn, bifurcation, 360° rotation, translation, lateral, omnidirectional
Drive Mode	McNamara wheel drive
Drive Power	DC 48V
Travel Speed	Straight: 0-40 m/min, Turning: 0-20 m/min
Repeat Positioning Accuracy	±5 mm
Permissible Road Flatness	≤5 mm
Working Mode	Continuous operation for 24 hours
Climbing Ability	≤5%
Charging Mode	Online charging (side charging)
Obstacle Sensor Safety Sensing Range	Detection distance: ≤3 m (adjustable), Sensor detection angle: ≤270° (adjustable), Emergency braking distance: < 20 mm
Safety Protection	Front obstacle detection sensor, double protection with safety touch-edge anti-collision mechanism, emergency stop switch
Alarm Form	Sound and light alarm
Work Noise	Below 70 dB (A)
Battery	Type: Lithium iron phosphate, Voltage: 48V, Capacity: 210Ah
Design Life	>10 years
